Der FireBird Pro S with mechanical stroke setting WHEN IS STROKE SETTING USED? A constant set stroke should be used when a blind rivet nut size of the same length is set in unchanging material thick- nesses. The set stroke corresponds to the distance the threaded mandrel is drawn into the nosepiece during the setting process and thus how far the blind rivet nut is compressed. With stroke setting, this distance can be adjusted mechanically on the riveting tool. ADVANTAGES OF STROKE SETTING
- Controlling the tool through stroke setting guarantees the height of the blind rivet nuts is constant after setting, regardless of any small variations in the nut or the material
- Infinitely variable adjustment of the set stroke
- Stroke setting is preferred above all by experienced users and for large series production TECHNICAL DATA Weight: 2.4 kg with battery (2.0 Ah) Traction power: 20,000 N Drive: brushless motor Stroke: 10.0 mm WORKING RANGE Blind rivet nuts up to M12 alu and steel and M10 stainless steel. SCOPE OF DELIVERY Threaded mandrel and nosepiece M6 (in working position), Threaded mandrel and nosepiece M8 and M10 (in magazine) 1x Hexagonal wrench 2x Double open ended wrench SW 24/27 1x Double open ended wrench SW 27/30 Card Quick adjustment Card Setting force pre-adjustment Operating manual
