FireFox 1F The hydropneumatique blind rivet nut tool with setting force adjustment for M3-M6 Advantages
- Easy to use, reliable and safe
- Sets small blind rivet nuts optimally and safely without damaging the material to be joined
- Setting takes place exclusively using setting force adjustment
- Optimum protection of the blind rivet nut thread
- Ergonomic design reduces fatigue when working Technical data Weight: 2 kg Maximum stroke: approx. 7.5 mm Adjustable traction force: up to approx. 12 kN at 6 bar Operating air pressure: 5-7 bar Air hose connection: 6 mm Ø (1/4’’) Air consumption: approx. 1-2 ltr.per setting process (depending on nutsize) Working range Blind rivet nuts from M3 up to M6 of all materials, except M6 stainless steel. Scope of delivery Threaded mandrel and nosepiece M6 (in working position) Threaded mandrel and nosepiece M3, M4 and M5 (in magazine) 2x double open ended wrenches SW 24/27 1x hexagon screw driver SW 3 1x oil refill bottle with hydraulic oil 100 ml 1x oil refill can Rubber foot Quick setting guide Colour code card Operating instructions with spare parts list
