FireFox 2F AxiaL eco Advantages
- Costs-effective entry model
- Ideally suited for instillation in assembly cells, fixtures or semi-automatic workstations
- Handy for processing blind rivet nuts in places that require vertical riveting action
- Can be attached to a balancer Working range Sets blind rivet nuts from M4 to M10 in all materials as well as M12 in aluminium and steel. Technical data Weight: 3.3 kg Max. setting stroke: 10 mm Drive: Pneumatic motor Setting force: 22 kN at 6 bar Operating pressure: 5-7 bar Hose connection: 6 mm Ø (1/4’’) Compressed air consumption: max. 2 l upt to 4 l per setting (depending on nut size) Scope of delivery Threaded mandrel and nosepiece M6 (in working position) Threaded mandrel and nosepiece M4, M5 and M8 (in magazine) 2x double open ended wrenches SW 24/27 1x hexagon screw driver SW 3 1x oil refill bottle with hydraulic oil 100 ml 1x oil refill can Quick setting guide Colour code card Operating instructions with spare parts list
