TAUREX 6 basic tool

TAUREX 1-6 The whole TAURUS series with remote pressure transducer – for even more flexibility, versatility and ergonomy ADVANTAGES

- Low weight of the hand held tool

- Tubing connection with quick-connect feature (upon request) on the pressure transducer side:

- No oil leak and no air bleeding

- Ideally suited for setting of blind rivets and lockbolts in poorly accessible locations

- Also perfectly designed for fixed installation in production lines or semi-automatic workstations

- Can be combined with almost all supplements and options of the TAURUS series: head extensions, mandrel containers, rivet counting units, process control, pressure trigger and remote control COMMON TECHNICAL DATA Operating air pressure: 5 to 7 bar Air hose connection: 6 mm (1/4“) Noise emission: max. 79 dB Vibrations: < 2.9 m/s² WORKING RANGE

- All blind rivets and lockbolts up to a mandrel

- breaking force of 50 kN

- Same performance and technical characteristics as the respective individual units in the TAURUS series 1-4,   5-6 with different stroke

- 3 metres hose length between pressure transducer and setting pistol Weight TAUREX 1

- 2,4 kg TAUREX 2

- 2,7 kg TAUREX 3

- 3,1 kg TAUREX 4

- 3,2 kg TAUREX 5

- 4,2 kg TAUREX 6

- 4,2 kg
