TAURUS 4 SRB with angle head 90° compact Advantages
- Hydro-pneumatic lock bolt setting device
- Accessibility in tight working spaces
- Light and compact design
- Modular structure
- Ergonomic handling Working range 6.4 lockbolts MagnaGrip* and C6L Technical data Weight: 2.2 kg Operating air pressure: 5-7 bar Schlauchanschluss: 6 mm Ø (1/4’’) Air hose connection: ca. 4.8 ltr. pro Niet Setting force: 23,000 N at 6 bar Stroke: 19 mm Scope of delivery Angle head with nosepiece in working position Swivelling hanger 1 hydraulic oil bottle 100 ml 1 oil refill can Operating instructions with spare parts list Lockbolts are used where there are particularly high requirements regarding the durability and vibration safety of the connection. The connection requires the components of the lockbolt to be accessible from two sides. Because the locking ring moulds into the retaining grooves during the setting process, the connection is extremely durable and secure against coming loose on its own. The GESIPA lock bolt setting devices in the TAURUS series have been developed using a modular concept and are an ideal composition of experience and consistent further development by our experienced engineers. The lockbolt setting devices guarantee high-quality setting processes and therefore long-lasting and permanently tight connections. In the truck & trailer field in particular, GESIPA devices ensure fast, troublefree working processes.
