The TAURUS series 1-4 in axial version – for special applications Applications The special pistols of TAURUS Axial offer the option of installation in production systems and simultaneously allow flexible and handheld ergonomic work in applications with restricted accessibility that require a vertical, downwards oriented riveting action. In order to ensure that no gap is left between the components to be riveted and the setting head effectively makes contact with the application, the TAURUS Axial can be additionally supplied with a spring loaded-trigger system. A compressed air supply is additionally required for reliable mandrel evacuation. Depending on the application, this is preferably achieved via the balancer with valve or the time delay valve. Working range
- Processing blind rivets up to 6.4 mm Ø all materials and up to 8 mm Ø alu (max. mandrel dia. 4.5 mm)
- Same performance and technical data as the respective individual units in the TAURUS series 1-4 Advantages
- Pressure transducer attached in a space-saving manner directly to the device, i.e. also for applications in tight spaces
- Technical design close to the TAUREX Axial
- Also perfectly designed for fixed installation in production lines or semi-automatic workstations
- Very practical for processing blind rivets in positions that require a vertical rivet setting process
- The tool can be equipped with almost all TAURUS series options: e.g. extension units, blind rivet counter, spring loaded trigger system and remote control
- The handle in the rivet axis allows ergonomic work – especially in vertical applications
- Can be suspended on a balancer Technical data Operating pressure: 5 to 7 bar Air hose connection: 6 mm (1/4“) Noise emission: max. 79 dB Vibrations: < 2.9 m/s² Weight: TAUREX 1 Axial compact 3.1 kg TAUREX 2 Axial compact 3.4 kg TAUREX 3 Axial compact 3.7 kg TAUREX 4 Axial compact 4.1 kg
