BULB-TITE Blind rivets
- Strong in demanding applications requiring perfect clamp force and weatherproofness. Originally designed for the construction industry, the GESIPA-BULB-TITE rivets have proven their worth in many other application fields thanks to their multifunctional properties. The majority of the BULB-TITE program has been approved by the „Deutsches Institut für Bautechnik“ in Berlin thereby guaranteeing extra security when used in steel constructions or on facades. Powerful wherever used Thanks to the shear zone overlap of the BULB-TITE-rivet mandrel in the application, permanent and very high shear forces can be achieved. Weather resistance The use of a special nosepiece when processing the BULB-TITE-rivet locks the mandrel into the sealing part on the setting head side to prevent dirt and/or damp penetrating the application. The sealing washer, which is available as an optional accessory, offers added protection against wet and damp below the closing head. Excellent clamping force The three large pressure plates distribute the clamping forces evenly across a large area of the surface so that even soft, thin, supple or brittle materials can be riveted safely without destroying or damaging the surface. Complex applications BULB-TITE- rivets also guarantee a safe function where other rivets have already given up. The three plates of the closing head adapt and form to fit even curved application surfaces so that safe riveting is possible even on pipes, beads and other unusually formed applications. Application areas Fassades, shipbuilding, containers, truck and passenger busses production, trailers, trapezoidal sheet metal roof Tthe advantages
- Large grip range
- Vibration-proof
- Use on straight and curved application parts
- Waterproof with neoprene sealing washer
- Large distirbution of the grip force over a large surface Please note that to achieve the best possible values from the GESIPA-BULB-TITE, use of special tools/ nosepieces is required. BULB-TITE blind rivets are available in small packs, too! Marked with the abbreviation KV.
