GESIPA Blind Rivets provice a lasting and safe joint for diverse and sensitive materials. GESIPA BLIND RIVETS – EFFICIENT TECHNOLOGY Life without blind rivet technology from GESIPA can no longer be imagined in modern industry production where fastening technology is required due to its efficiency and versatility. It combines the advantages of overcoming restricted component accessibility, permanently safe connection of different, and specialised materials, and even documentation of the setting process if required. Technically speaking, the blind rivet consists of two parts: the rivet body and the mandrel. During screw-connecting, clinching and punch riveting etc. the application must always be accessible on both sides but the special thing about blind riveting is that the application only needs to be accessed from one side. GESIPA Blind Rivets – Connections that last During the setting process, the mandrel is pulled by the jaws of the setting tool and forms the rivet body to the predefined fixed position in the application. The mandrel then breaks off at the intended point (the target breakage point) and can be recycled. The filling cut (this is the remaining rest of mandrel in the rivet body) can provide an additional securing function depending on the application. GESIPA Blind Rivets
- For every application Blind rivets are available in a variety of designs, materials, forms, lengths and even colours. Depending on the task which the blind rivet should fulfil, GESIPA can choose between a standard model available from stock or a blind rivet specially designed for the application. GESIPA Blind Rivets – A rule of thumb Material thickness + rivet diameter = rivet body length Technical data on GESIPA Blind Rivets GESIPA-Blind Rivets – Definitions
- The blind rivet consists of two parts: the blind rivet head and the mandrel body.
- The rivet body consists of the setting head and the shaft.
- The setting head is found on the processing side and is variable in diameter and shape. There are dome, countersunk and large flange versions. The rivet body is available in different lengths depending on the material thickness to be riveted.
- The rivet mandrel is used to deform the rivet body. It contains the predetermined breaking point This is where the rivet mandrel breaks after the rivet has deformed.
- The rest mandrel is the remaining part of the rivet mandrel in the rivet body. The residual mandrel is the part of the rivet mandrel that is disposed of from the set rivet via the blind rivet setting tool.
