FireFox 1F Axial eco The hydropneumatic blind rivet nut tools for working vertically Advantages
- Costs-effective entry model
- Ideally suited for instillation in assembly cells, fixtures or semi-automatic workstations
- Handy for processing blind rivet nuts in places that require vertical riveting action
- Can be attached to a balancer Working range Blind rivet nuts from M3 up to M6 of all materials, except M6 stainless steel. Technical data Weight: 2.8 kg Max. setting stroke: approx. 7.5 mm Max. setting force, adjustable: approx. 12 kN at 6 bar Operating pressure: 5-7 bar Hose connection: 6 mm Ø (1/4’’) Compressed air consumption: max. 2 l per setting (depending on nut size) Scope of delivery Threaded mandrel and nosepiece M6 (in working position) Threaded mandrel and nosepiece M3, M4 and M5 (in magazine) 2x double open ended wrenches SW 24/27 1x hexagon screw driver SW 3 1x oil refill bottle with hydraulic oil 100 ml 1x oil refill can Rubber foot Quick setting guide Colour code card Operating instructions with spare parts list
