TAUREX 4 Axial

TAUREX Axial 1

- 4 The TAURUS series 1-4 with remote mounted pressure transducer in axial version – making it more flexible, versatile and ergonomic. Applications The TAUREX Axial is a particular advantage in restricted spaces due to the separate pressure transducer mounted in the working direction. The special pistols of TAUREX Axial offer the option of installation in production systems and simultaneously allow flexible and handheld ergonomic work in applications with restricted accessibility that require a vertical, downwards oriented riveting action. In order to ensure that no gap is left between the components to be riveted and the setting head effectively makes contact with the application, the TAUREX Axial can be additionally supplied with a spring-loaded trigger system. It is essential to use an external suction system with the TAUREX Axial! A compressed air supply is additionally required for reliable mandrel evacuation. Depending on the application, this is preferably achieved via the balancer with valve or the time delay valve. Technical data Operating air pressure: 5 to 7 bar Air hose connection: 6 mm (1/4“) Noise emission: max. 79 dB Vibrations: < 2.9 m/s² Weight: TAUREX 1 Axial 2.4 kg TAUREX 2 Axial 2.7 kg TAUREX 3 Axial 3.0 kg TAUREX 4 Axial 3.1 kg Working range

- Sets blind rivets up to 6.4 mm Ø all materials and up to 8 mm Ø alu (max. mandrel dia 4.5 mm)

- Same performance and technical data as the respective TAURUS series 1-4

- 3 metre hose length between pressure transducer and setting pistol Advantages

- Also perfectly designed for fixed installation in production lines or semi-automatic workstations

- Very practical for processing blind rivets in positions hat require a vertical rivet setting process

- Low weight of the hand held tool

- Tubing connection with quick-connect feature (upon request) on the pressure transducer side:   No oil leak and no air bleeding

- The tool can be equipped with almost all TAURUS series options: e.g. extension units, blind rivet counter,   spring loaded trigger system and remote control

- The handle in the rivet axle allows ergonomic work – especially in vertical applications

- Can be suspended on a balancer
