TAURUS 3 SRB Advantages
- Specially adjusted stroke for setting lockbolts
- Very high tensile strength allows fast setting
- Extremely handy and leightweight due to its compact design
- Economic consumption of compressed air
- Minimum wear and tear due to use of pulling head modules with jaws respectively adjusted in their numbers of parts
- Efficient operation through extraction of spent mandrels
- Large spent mandrel container
- Attractive price-performance ratio
- Modular structure Working range 4.8 lockbolts MagnaGrip* and C6L Technical data Weight: 2.0 kg Operating air pressure: 5
- 7 bar Air hose connection Ø: 6 mm Air consumption: 4.8 NL / stroke Traction power: 18,000 N at 6 bar Stroke: 25 mm Scope of delivery 1 hydraulic oil bottle 100 ml 1 oil refill can Hanger on tool head Operating instructions with spare parts list Lockbolts are used where there are particularly high requirements regarding the durability and vibration safety of the connection. The connection requires the components of the lockbolt to be accessible from two sides. Because the locking ring moulds into the retaining grooves during the setting process, the connection is extremely durable and secure against coming loose on its own. The GESIPA lock bolt setting devices in the TAURUS series have been developed using a modular concept and are an ideal composition of experience and consistent further development by our experienced engineers. The lockbolt setting devices guarantee high-quality setting processes and therefore long-lasting and permanently tight connections. In the truck & trailer field in particular, GESIPA devices ensure fast, troublefree working processes.
